2025 Suzuki KingQuad 500AXi Power Steering
Color Options
Desert Beige: +$0
Terra Green: +$0
Flame Red: +$0
Pricing
Warranty (Months): 24
Engine
Engine Type: Single-Cylinder
Cylinders: 1
Cooling: Liquid
Bore: 87.5 mm; 3.4 in
Stroke: 82 mm; 3.2 in
Displacement: 493 cc; 30 ci
Compression Ratio: 9.9:1
Starter: Electric
Fuel Type: Gas
Emissions Standards: Meets California Emissions
Carburetion Type: Fuel Injected
Transmission
Transmission Type: Continuously Variable (CVT)
Reverse: Yes
Drive Line
Driveline Type: Selectable 4X2 / 4X4
Technical Specifications
Length: 84.6 in; 2150 mm
Width: 47.8 in; 1215 mm
Height: 50.6 in; 1285 mm
Wheelbase: 50.6 in; 1285 mm
Ground Clearance: 10.2 in; 260 mm
Wet Weight: 714 lbs; 324 kg
Towing Capacity: 1322 lbs; 599.7 kgs
Fuel Capacity: 4.6 gal; 17.5 l
Storage Capacity: 0.6 gal
Exterior
Frame: Steel
Suspension
Front Suspension Type: Independent Double A-Arm
Front Travel: 6.7 in; 170.2 mm
Rear Suspension Type: Independent Double A-Arm
Rear Travel: 7.7 in; 195.6 mm
Wheels & Tires
Front Tire (Full Spec): Carlisle AT 25 X 8-12
Rear Tire (Full Spec): Carlisle AT 25 X 10-12
Brakes
Front Brake Type: Dual Hydraulic Disc
Rear Brake Type: Sealed Oil Bath Multi-Disc
Seats
Seat Height: 37 in; 940 mm
Number Of Seats: 1
Instrumentation
Speedometer: Standard
Trip Odometer: Standard
Lights
Type: Halogen
- New
- SAS101176
- 2025
- Suzuki
- KingQuad 500AXi Power Steering
- ATV
- Utility
- 5SADW21EXS7101176
- 0
- Single-Cylinder
- Gas
- 4-stroke, 4-valve, OHC single cylinder
- 493cc (30.1 cubic in.)
- Liquid-cooled
- 87.5 mm (3.40 in.)
- 82.0 mm (3.20 in.)
- 9.9:1
- Suzuki electronic fuel injection
- Electric
- Wet sump
- Electronic ignition (transistorized)
- Automatic variable ratio (V-belt), with high/low-range, and reverse
- Dry shoe, automatic, centrifugal type
- Shaft drive
- Independent, double wishbone, coil spring, gas charged and oil damped with 5-way preload adjustable shock absorbers
- Independent, double wishbone, coil spring, gas charged and oil damped with 5-way preload adjustable shock absorbers
- Disc brakes, twin rotors
- Sealed oil-bathed multi-disc
- 2WD, 4WD and 4WD Differential Lock
- AT25 x 8-12, tubeless type x 2
- AT25 x 10-12, tubeless type x 2
- 2150 mm (84.6 in.)
- 1215 mm (47.8 in.)
- 1285 mm (50.6 in.)
- 1285 mm (50.6 in.)
- 260 mm (10.2 in.)
- 920 mm (36.2 in.)
- 17.5 L (4.6 US gal.)
- 324 kg (714 lb.), 325 kg (716 lb.) CA model
- Desert Beige
- 12V 35/35W x 2 fender-mounted, 12V 35W x 1 handlebar-mounted
- LED
- Warranty: 24-month limited warranty | Extension: Longer coverage periods with other benefits are available through Suzuki Extended Protection (SEP)
